QGM Block Ua Tshuab Yuav Ua Li Cas Ntxiv Cov Khoom Siv Txhua Hnub hauv Cov Khoom Siv Uas Siv Ua Haujlwm?

Rau cov pob zeb thaiv cov tuam txhab, cov khoom tsim tawm txhua hnub yog ib qho kev ntsuas tseem ceeb tshaj plaws uas txiav txim siab txog kev muaj txiaj ntsig thiab kev sib tw. CovQGM Block Ua Tshuabxa cov khoom lag luam ntau ntxiv hauv txhua hnub los ntawm kev sib xyaw ua ke ntawm cov cuab yeej siv siab tshaj plaws, hydraulic overpressure systems, thiab tag nrho cov khoom siv automated tuav. Tsis zoo li cov tshuab thaiv cov tshuab uas tso siab rau cov cuab yeej siv yooj yim, peb QGM Block Making Machine siv lub tshuab servo-tsav high-frequency vibration system uas ua tiav 5,500 txog 6,500 rpm, txo lub voj voog tsim kom tsawg li 12 vib nas this ib pallet. Qhov no txhais tau hais tias tus qauv 8-teev ua haujlwm tuaj yeem tsim tau 12,000 rau 15,000 tus qauv blocks (400x200x200mm) piv rau 7,000 rau 8,000 blocks los ntawm cov qauv qub. Peb lub Hoobkas ntawm Quangong Machinery Co., Ltd. tau sau cov ntaub ntawv tso tawm tau nce ntawm 55 feem pua ​​​​hauv kev sim thoob plaws 12 lub teb chaws. Kab lus no piav qhia txog cov yam ntxwv tshwj xeeb engineering uas ua rau qhov kev tsim khoom tau nce siab.

Tab sis cov zis tsis yog tsuas yog hais txog lub voj voog ceev. QGM Block Making Machine nce txhua hnub ntau lawm los ntawm kev txo qis qis los ntawm kev kuaj xyuas ntse, hloov pwm ceev (hauv qab 5 feeb), thiab lub zog txuag hluav taws xob hydraulic twj uas txo cov cua sov, tso cai rau kev ua haujlwm tas mus li 20 teev hauv ib hnub. Moreover, our machine integrates with a centralized control system that monitors concrete moisture, aggregate feed, and vibration intensity in real time, ensuring that every block meets density and strength standards without the need for manual adjustments. Rau cov tswv ntawm lub Hoobkas, qhov no txhais tau hais tias muaj txiaj ntsig ntau ntxiv rau ib qho kev hloov pauv, tus nqi qis dua rau ib chav tsev, thiab rov qab sai dua ntawm kev nqis peev. Nyob rau hauv phau ntawv qhia no, peb rhuav tshem cov tshuab, hydraulic, thiab kev tswj cov tshuab uas ua rau QGM Block Making Machine ib qho kev ua si hloov pauv rau cov nroj tsuag thaiv thoob ntiaj teb. Peb kuj qhia cov ntaub ntawv kev ua tau zoo thiab kev saib xyuas kev pom zoo los ntawm Quangong Machinery Co., Ltd.

Cov Lus Qhia

• 1. Yog vim li cas thiaj li High-Frequency Vibration Dramatically Shorten lub voj voog ntawm QGM Block Making Machine?
• 2. Yuav ua li cas Hydraulic Overpressure thiab Servo Tsav Systems Boost Txhua Hnub Tso Tawm?
• 3. Dab tsi yog Cov Lus Qhia Tshwj Xeeb ntawm Peb QGM Block Making Machine?
• 4. Yuav ua li cas thiaj li ntse Automation thiab hloov pwm ceev txo lub sij hawm tsis tsim khoom?
• Cov lus nug nquag nug (FAQ)
• Xaus thiab Action Plan rau cov zis ntau dua

Yog vim li cas thiaj li High-Frequency Vibration Dramatically Shorten lub voj voog ntawm QGM Block Making Machine?

Lub voj voog tsim ntawm lub tshuab ua tshuab yog lub sijhawm los ntawm cov khoom siv raw khoom noj mus rau ejection ntawm cov blocks tiav. Hauv cov tshuab tsoos, kev vibration zaus ntawm 2,800 txog 3,800 rpm, uas yuav tsum tau 18 mus rau 25 vib nas this ntawm kev co kom ua tiav cov compaction txaus. Lub sij hawm ncua kev vibration no tsis tsuas yog qeeb ntau lawm tab sis kuj ua rau ntxov ntxov hnav ntawm bearings thiab pwm liners. Peb QGM Block Ua Tshuab ntiav ob lub zog eccentric vibrator uas tau tsav los ntawm kev ywj pheej servo motors, xa cov kev vibration quab yuam ntawm 120 kN ntawm 6,200 rpm. Qhov no high-frequency, high-amplitude ua ke compacts lub pob zeb sib tov nyob rau hauv 8 mus rau 12 vib nas this, txo tag nrho cov tsim voj voog los ntawm ze li ntawm 50 feem pua. Peb lub Hoobkas tau ntsuas tias qhov no ib leeg nce cov zis txhua hnub los ntawm 35 feem pua.

Cov yam tseem ceeb uas ua rau muaj kev vibration siab zoo hauv peb QGM Block Making Machine:

• Accelerated particle rearrangement:Ntawm 6,200 rpm, cov khoom sib xyaw ua ke tau nrawm dua, tshem tawm cov voids thiab cov hnab ntim cua. Qhov no txhais tau tias tsawg dua lub sijhawm vibration yog xav tau kom ncav cuag lub hom phiaj ceev (2.2 g / cm3 rau hollow blocks).
• Resonance zam algorithm:Peb lub tshuab PLC kho qhov kev vibration zaus hauv lub sijhawm tiag tiag kom tsis txhob muaj qhov cuam tshuam ntawm cov pwm thiab pallet, kom ntseeg tau tias lub zog siab tshaj plaws hloov mus rau hauv qhov sib tov es tsis txhob siv hluav taws xob los yog suab nrov.
• Dual-frequency xaiv:QGM Block Ua Tshuab tso cai rau cov neeg ua haujlwm xaiv ntawm qhov tsawg zaus (2,800 rpm) rau cov sib xyaw ntub dej thiab cov zaus siab (6,200 rpm) rau cov khoom sib tov qhuav, optimizing compaction rau cov khoom noj sib txawv yam tsis ua kom lub voj voog qeeb.
• Instant nres thiab thim rov qab braking:Tom qab compaction, qhov kev vibration yuav tsum tsis pub dhau 0.5 vib nas this, tso cai rau lub pallet ejection tam sim ntawd. Cov tshuab tsoos xav tau 2 mus rau 3 vib nas this rau kev vibration kom lwj, ntxiv lub sijhawm tsis tsim nyog rau ib lub voj voog.

Cov ntaub ntawv teb los ntawm cov nroj tsuag thaiv hauv Indonesia siv QGM Block Making Machine pom tias lub voj voog tsim tau txo qis los ntawm 22 vib nas this mus rau 12.5 vib nas this, nce kev hloov pauv ntawm 9,800 blocks rau 16,200 blocks. Tus tswv cog tau tshaj tawm tias lub tshuab them nyiaj rau nws tus kheej hauv cov khoom siv ntxiv hauv 7 lub hlis. Peb lub Hoobkas tseem tsim cov kev vibration system nrog cov roj-txias bearings uas tswj qhov kub ntawm 65 ° C txawm nyob rau ntawm 6,200 rpm tas mus li kev khiav hauj lwm, tshem tawm qhov xav tau rau txias-down so uas plague qis-kawg tshuab. Qhov kev ruaj ntseg thermal no tso cai rau QGM Block Making Machine los txhawb kev tsim khoom siab tshaj plaws rau 20-teev hnub, uas yog qhov tseem ceeb rau cov phiaj xwm loj loj. Nyob rau hauv cov ntsiab lus, lub high-frequency vibration system tsis yog ib tug ceev lub cev muaj zog - nws yog ib tug ua tiav optimization ntawm lub zog hloov, compaction physics, thiab thermal tswj uas compresses lub voj voog lub sij hawm thiab qhib ib theem tshiab ntawm cov zis txhua hnub.

Lwm qhov kom zoo dua ntawm lub tshuab hluav taws xob ntau yog tias nws tsim cov blocks nrog lub zog ntsuab ntau dua (lub zog tam sim ntawd tom qab tsim), tso cai ua ntej demolding thiab ceev pallet turnover. Qhov no txhais tau tias tsawg dua pallets xav tau nyob rau hauv qhov chaw kho, txo cov peev txheej ntawm cov khoom pallets thiab racks. Peb lub Hoobkas ntawmQuangong Machinery Co., Ltd.tau ua ke nrog kev vibration siv saib xyuas uas qhia txog lub zog ntawm lub sijhawm sib npaug ntawm ib lub voj voog, pab cov neeg ua haujlwm kho cov qauv tsim kom ua tiav lub zog ntsuab nrog lub sijhawm luv tshaj plaws. Qhov kev tawm tswv yim kaw qhov kaw no yog qhov tshwj xeeb rau QGM Block Making Machine thiab yog qhov laj thawj tseem ceeb vim li cas peb cov neeg siv khoom tsis tu ncua tshaj tawm cov duab tso tawm txhua hnub tshaj lawv qhov kev kwv yees qub.

Yuav ua li cas Hydraulic Overpressure thiab Servo Tsav Systems Boost Txhua Hnub Tso Tawm?

Thaum kev vibration yog qhov tseem ceeb rau kev compaction, hydraulic siab yog dab tsi muab lub thaiv nws qhov kawg ntom thiab qhov tseeb qhov tseeb. Peb QGM Block Ua Tshuab nta ib lub tshuab hydraulic dual uas siv ob qho tib si nias (txog 280 bar) thiab ejection siab (txog 160 bar) nyob rau hauv ib tug synchronized ib ntus. Lub tog raj kheej hydraulic muab lub zog ntawm 1,200 kN ntawm lub taub hau pwm, uas, ua ke nrog kev co, ua cov blocks nrog compressive zog tshaj 20 MPa (rau hollow blocks) thiab 35 MPa (rau cov khoom blocks) yam tsis tau ncua lub sij hawm voj voog. Tab sis qhov tseem ceeb tshaj, peb lub tshuab hydraulic siv cov twj siv hluav taws xob sib txawv-ceev servo uas txo cov kev siv hluav taws xob los ntawm 40 feem pua ​​​​thaum nce lub voj voog ceev los ntawm 25 feem pua ​​​​piv rau cov twj tso kua mis ruaj khov.

Nov yog yuav ua li cas hydraulic thiab servo technologies txhim kho cov zis hauv QGM Block Making Machine:

• Servo-tsav hydraulic twj tso kua mis:Lub servo lub cev muaj zog tsuas yog rub lub zog thaum nias thiab ejection theem, idling ntawm zero zog thaum pub mis thiab vibration. Qhov no txo ​​qhov tsim hluav taws xob, tso cai rau lub luag haujlwm ntau dua yam tsis muaj roj overheating. Peb lub Hoobkas tau sim ua haujlwm tsis tu ncua rau 22 teev nrog roj kub nyob hauv qab 55 ° C.
• Pressure accumulator bank:Plaub hydraulic accumulators khaws cov roj siab thiab tso tawm thaum lub sij hawm nias, ua tiav siab (280 bar) hauv 0.8 vib nas this. Cov twj tso kua mis ib txwm xav tau 2.5 vib nas this los tsim lub siab, txuag 1.7 vib nas this ib lub voj voog.
• Kev ua ib txhij:Lub PLC tswj xyuas servo-tsav kev co thiab hydraulic nias kom ob lub tshuab ua haujlwm nyob rau hauv lub sijhawm sib tshooj. Piv txwv li, cov xovxwm hydraulic pib nws cov hlab ntsha thaum vibration tseem ua haujlwm, txo tag nrho lub sijhawm voj voog los ntawm 2 vib nas this ib block.
• Tsis siv neeg siab them nyiaj:Raws li cov pwm kab noj hniav puv, lub tshuab hydraulic kho lub zog nias raws li cov pob zeb ua haujlwm, kom ntseeg tau tias qhov siab ntawm qhov thaiv tsis dhau-compressing lossis qis dua. Qhov no tshem tawm kev sim-thiab-kev hloov kho uas nkim sijhawm thiab tsim cov khoom seem.

Txhawm rau kom muaj nuj nqis ntawm kev txhim kho cov khoom tsim tawm, peb muab piv rau cov khoom siv hydraulic thaiv tshuab (tso twj tso kua mis, tsis muaj servo) nrog peb QGM Block Making Machine hauv kev sim ib sab. Lub tshuab pa tau tsim 8,400 blocks ib 8-teev ua haujlwm ntawm 18-thib ob lub voj voog. Peb QGM Block Ua Tshuab, nrog servo hydraulics thiab siab accumulators, tsim 13,200 blocks ntawm 13-thib ob cycles-a 57 feem pua ​​​​nce. Lub tshuab servo kuj txo cov kev siv hluav taws xob ib ntu ntawm 0.38 kWh rau 0.21 kWh, txo cov nqi khiav lag luam thiab tso cai rau lub Hoobkas khiav cov cav tov ntxiv ntawm tib lub tshuab hluav taws xob. Rau qhov nruab nrab-loj thaiv cov nroj tsuag nrog ob lub tshuab, hloov mus rau QGM Block Making Machine tuaj yeem ntxiv 2,800 blocks rau ib qho kev hloov pauv yam tsis muaj kev nthuav dav.

Ntxiv mus, hydraulic system ntawm peb QGM Block Making Tshuab suav nrog ceev-clamp pwm kho mechanism uas txo pwm hloov lub sij hawm ntawm 15 feeb mus rau hauv 4 feeb. Qhov no txhais tau hais tias cov khoom hloov pauv (los ntawm hollow blocks mus rau pavers rau curb pob zeb) siv sij hawm tsawg dua, ua tau zoo ntxiv cov sij hawm tsim nyog rau txhua hnub. Peb lub Hoobkas tau nruab txhua lub QGM Block Ua Tshuab nrog lub ntsuas siab digital thiab ntsuas ntsuas ntsuas uas ntsuas kev ua haujlwm hydraulic, ua kom muaj kev saib xyuas zoo. Qhov no tiv thaiv kev poob siab uas tsis xav txog uas yuav txwv tsis pub ntau ntau teev. Hauv cov ntsiab lus, kev sib xyaw ua ke ntawm servo hydraulics, accumulators, thiab kev tswj ntse tsis tsuas yog ua kom nrawm dua txhua lub voj voog tab sis kuj tseem txuas ntxiv lub tshuab ua haujlwm txhua hnub qhov rais, ncaj qha boosting tag nrho cov zis.

Dab tsi yog Cov Lus Qhia Tshwj Xeeb ntawm Peb QGM Block Making Machine?

QGM muaj peb tus qauv tseem ceeb ntawm QGM Block Making Machine, txhua qhov tsim kom muaj peev xwm ntau lawm thiab thaiv hom. Cov lus hauv qab no qhia txog qhov tseem ceeb ntawm cov khoom uas txiav txim siab qhov muaj peev xwm tsim tawm txhua hnub. Tag nrho cov ntaub ntawv yog raws li tus qauv hollow block qhov ntev (400x200x200mm) nrog kev sib xyaw tsim ntawm 1: 2: 4 (cement: xuab zeb: aggregate). Peb lub Hoobkas tuaj yeem hloov kho txhua qhov tshwj xeeb kom tau raws li cov qauv hauv cheeb tsam lossis cov phiaj xwm tshwj xeeb.

Tshaj li tus qauv tshwj xeeb, QGM Block Making Machine muaj ntau yam kev xaiv los txhim kho ntxiv kom nce cov zis txhua hnub. Cov no suav nrog cov txheej txheem stacker uas tuaj yeem tshem tawm cov pallets tiav thiab hloov lawv nrog cov khoob khoob, tshem tawm phau ntawv tuav lub sijhawm (txuag 2 feeb ib lub voj voog). Lwm qhov kev xaiv yog kev sib koom ua ke chamber curing, uas siv cov khoom siv hluav taws xob pov tseg los ntawm cov hydraulic system kom ceev thaiv kev kho, txo lub sijhawm kho ntawm 24 teev mus rau 12 teev thiab tso cai rau rov siv dua pallet sai dua. Peb lub Hoobkas kuj tseem muab cov chaw taws teeb saib xyuas cov chaw taws teeb uas tso cai rau cov neeg tswj xyuas cov nroj tsuag taug qab cov ntaub ntawv tsim khoom ntawm lawv lub xov tooj smartphones, ua kom cov lus teb ceev ceev rau txhua qhov fwj.

Hais txog kev ntseeg tau, txhua lub QGM Block Ua Tshuab tau dhau 72-teev kev sim mus tas li ntawm peb lub Hoobkas ua ntej xa khoom, simulating tag nrho cov khoom ntim nrog 15-thib ob cycles. Peb lav tias lub tshuab yuav tswj hwm nws cov khoom tso tawm tsawg kawg 8,000 teev ua haujlwm ua ntej yuav tsum tau hloov cov khoom tseem ceeb. Cov khoom siv-pwm liners, vibration shafts, thiab hydraulic seals-yog tsim los hloov tau yooj yim nrog cov cuab yeej txheem, txo qis lub sij hawm poob. Quangong Machinery Co., Ltd. stocks spare qhov chaw rau tag nrho QGM Block Ua Tshuab qauv ntawm lub regional warehouses, kom ntseeg tau tias ib qho kev hloov pauv tuaj yeem xa tuaj tsis pub dhau 48 teev thoob ntiaj teb. Cov pob nyiaj pab txhawb nqa no ua kom ntseeg tau tias koj cov khoom tso tawm txhua hnub tseem nyob ruaj khov siab thoob plaws lub tshuab lub neej.

Yuav Ua Li Cas Ntse Automation thiab Hloov Pwm Ceev Yuav Txo Lub Sijhawm Tsis Tsim Nyog?

Cov zis txhua hnub tsis yog hais txog lub voj voog ceev xwb - nws tseem yog hais txog kev ua kom lub sijhawm ntau lawm. Ntau lub tuam txhab thaiv kev poob 15 mus rau 25 feem pua ​​​​ntawm cov khoom tsim tawm vim kev teeb tsa kev hloov pauv, kev saib xyuas, thiab kev tuav cov khoom qeeb. QGM Block Making Machine tackles cov kev tsis tsim tawm los ntawm kev sib koom ua ke automation uas tswj txhua yam los ntawm kev sib sau ua ke rau pallet stacking. Peb lub Hoobkas tau tsim lub tshuab software los cuam tshuam nrog batching nroj tsuag, conveyors, thiab lub voos xwmfab handlers, tsim kom muaj seamless ntau lawm kab. Qhov no txo ​​cov kev cuam tshuam ntawm phau ntawv thiab tshem tawm lub sijhawm tos ntawm lub voj voog.

Cov yam ntxwv tshwj xeeb ntawm peb QGM Block Ua Tshuab uas txo cov sij hawm tsis tsim khoom:

• Tsis siv neeg pwm qhov siab hloov kho:Lub tshuab PLC khaws txog 50 qhov sib txawv qhov siab qhov chaw. Thaum hloov cov khoom, tus neeg teb xov tooj xaiv qhov profile, thiab lub tshuab yuav hloov kho lub pwm sab saud, stripping pin sij hawm, thiab lub sijhawm vibration. Qhov no txiav lub sijhawm teeb tsa los ntawm 25 feeb mus rau qis dua 3 feeb.
• Quick-hloov pwm clamping:Peb patented wedge-lock system ruaj cov pwm nrog plaub hydraulic clamps uas tso tawm thiab koom ua ke ib txhij. Kev hloov pwm tuaj yeem ua tiav hauv 4 feeb los ntawm ib tus neeg teb xov tooj, piv rau 20 feeb nrog cov tsoos bolt-on pwm.
• Automated pallet feeder thiab stacker:QGM Block Ua Tshuab tuaj yeem nruab nrog cov ntawv xov xwm pallet uas pub cov khoom seem pallets txhua lub voj voog thiab cov txheej txheem stacker uas ua tiav cov pallets rau hauv lub voos xwmfab. Qhov no tshem tawm qhov xav tau rau cov neeg ua haujlwm pallet tshwj xeeb, txuag 2 mus rau 3 tus neeg ua haujlwm ib zaug.
• Diagnostic self-check:Thaum pib ntawm txhua hnub, lub tshuab ua haujlwm 2-feeb kev kuaj tus kheej li niaj zaus uas kuaj xyuas hydraulic siab, servo tawm tswv yim, kev vibration tshuav nyiaj li cas, thiab qib roj. Txhua qhov teeb meem tau tshwm sim ntawm lub vijtsam kov nrog cov lus pom zoo, tiv thaiv kev ua txhaum me me los ntawm kev nce mus rau kev tsim khoom-tso tseg.

Txhawm rau qhia txog cov txiaj ntsig zoo ntawm cov automation nta, peb tau taug qab lub Hoobkas thaiv hauv Nyab Laj ua ntej thiab tom qab txhim kho peb QGM Block Making Machine. Ua ntej kev txhim kho, lub Hoobkas nruab nrab 6.5 teev ntawm kev tsim khoom tiag tiag ntawm 8-teev ua haujlwm vim muaj pwm hloov, kev tuav pallet tuav, thiab kev tawg me me. Tom qab kev teeb tsa, lub sijhawm tsim khoom tiag tiag tau nce mus rau 7.8 teev ib zaug ua haujlwm - 20 feem pua ​​​​nce hauv lub sijhawm ua haujlwm. Ua ke nrog lub sij hawm voj voog sai, cov zis txhua hnub ntau dua ob npaug, los ntawm 5,200 blocks rau 12,900 blocks. Tus thawj coj ntawm lub Hoobkas tau tshaj tawm tias lawv tuaj yeem txo cov neeg ua haujlwm ntawm 14 mus rau 9 tus neeg ua haujlwm thaum nce cov khoom tsim tawm, txo cov nqi ua haujlwm ib ntus.

Lwm lub sij hawm khaws cia yog qhov tsis siv neeg pom cov roj uas tsis tu ncua ntxuav cov kua dej hydraulic, txuas ntxiv roj lub neej mus rau 6,000 teev (piv rau 1,500 teev hauv cov tshuab tsis pom). Qhov no txo ​​qhov zaus ntawm kev hloov roj, txhua qhov yuav siv li 2 teev thiab xav kom lub tshuab kaw. Tshaj ib xyoos, qhov no ntxiv 8 mus rau 10 hnub ua haujlwm. Peb lub Hoobkas ntawm Quangong Machinery Co., Ltd. muab kev cob qhia kev cob qhia rau cov neeg ua haujlwm, kom ntseeg tau tias lawv tuaj yeem siv tag nrho cov yam ntxwv ntawm automation txij hnub ib. QGM Block Ua Tshuab yog tsim los ua tus neeg siv khoom zoo, nrog rau cov xim touchscreen interface uas qhia txog lub voj voog, cov lus ceeb toom, thiab cov duab ua haujlwm zoo. Los ntawm kev txo qis lub sijhawm tsis tsim khoom los ntawm kev siv lub tshuab ntse ntse, peb lub tshuab ua kom thaiv cov chaw tsim khoom kom ua tau raws li qhov xav tau thiab txawm tias dhau lawv lub hom phiaj tso tawm txhua hnub.

Cov lus nug nquag nug (FAQ)

Nqe Lus Nug 1: QGM Block Ua Tshuab ntau npaum li cas tuaj yeem nce cov zis txhua hnub piv rau tus qauv hydraulic thaiv tshuab?

Teb: Raws li cov ntaub ntawv teb los ntawm ntau tshaj 50 qhov kev teeb tsa, QGM Block Making Machine feem ntau nce cov zis txhua hnub los ntawm 40 mus rau 60 feem pua. Piv txwv li, tus qauv hydraulic tshuab tsim 7,500 blocks ib 8-teev ua haujlwm tuaj yeem hloov tau los ntawm QGM 8S qauv, uas ua rau 12,500 mus rau 13,500 blocks hauv tib qho kev hloov, ntxiv 5,000 ntxiv blocks txhua hnub. Qhov kev nce no los ntawm kev vibration siab (lub sij hawm luv luv), servo hydraulic system (ntxhiab nrawm), thiab hloov pwm ceev (tsawg downtime). Peb lub Hoobkas muab cov khoom tso tawm dawb simulation raws li koj qhov tam sim no sib xyaw thiab thaiv hom. Ntau tus neeg siv khoom rov qab siv lub tshuab peev hauv 8 mus rau 12 lub hlis nkaus xwb los ntawm cov khoom siv ntxiv.

Nqe Lus Nug 2: Dab tsi yog qhov tseem ceeb uas cuam tshuam rau qhov tseeb niaj hnub tso tawm ntawm QGM Block Making Machine?

Teb: Cov ntsiab lus tseem ceeb yog: pob zeb sib xyaw ua ke (ntub vs. qhuav sib xyaw cuam tshuam rau lub sijhawm vibration); theem kev txawj ntawm tus neeg teb xov tooj (cov neeg ua haujlwm tau kawm tuaj yeem txo lub sijhawm voj voog los ntawm 1-2 vib nas this); raw cov ntaub ntawv noo noo (cov av noo siab dua 8 feem pua ​​​​yuav tsum muaj kev vibration ntev dua); thiab pwm complexity (cov duab intricate yuav siv sij hawm me ntsis ntev). Peb QGM Block Ua Tshuab tuaj yeem kho qhov kev vibration siv thiab nias lub zog los them nyiaj rau kev sib xyaw ua ke, tab sis cov khoom siv zoo ib yam ua rau cov khoom siv siab tshaj plaws. Tsis tas li ntawd, cog layout-tshwj xeeb yog qhov kev ncua deb ntawm cov nroj tsuag batching, lub tshuab, thiab qhov chaw kho-tuaj yeem cuam tshuam rau lub sijhawm voj voog vim lub sijhawm thauj khoom pallet. Peb lub Hoobkas muab kev sab laj layout los optimize cov logistics.

Nqe Lus Nug 3: QGM Block Making Machine puas tuaj yeem khiav 24 teev hauv ib hnub yam tsis tau txo cov zis?

Teb: Yog, QGM Block Making Machine yog tsim los rau kev ua haujlwm tas mus li, yog tias tau teem sijhawm ua haujlwm. Lub servo hydraulic system tsim hluav taws xob tsawg dua li cov twj tso kua mis ruaj khov, thiab cov roj-txias kev co bearings tso cai 24/7 khiav. Txawm li cas los xij, peb xav kom 30-feeb tu txhua txhua 12 teev rau kev kuaj pom thiab lubrication. Hauv kev ua haujlwm 24-teev ib txwm ua haujlwm (peb lub sijhawm ua haujlwm), peb lub tshuab tuaj yeem tsim tau 36,000 rau 40,000 blocks (siv QGM 8S qauv) nrog cov khoom tsim nyog thiab pallet ncig. Ntau ntawm peb cov neeg siv khoom ua haujlwm 20 teev hauv ib hnub (ob lub sijhawm ua haujlwm 10-teev) kom tso cai rau ib teev ib zaug rau kev ntxuav thiab hloov kho, ua tiav ntau dua 85 feem pua ​​​​ntawm cov txiaj ntsig siab tshaj plaws.

Nqe Lus Nug 4: Lub sij hawm hloov pwm cuam tshuam li cas rau cov zis txhua hnub, thiab qhov kev hloov pauv ceev npaum li cas ntawm QGM Block Making Machine?

Teb: Pwm hloov yog ib qho kev tua neeg loj hauv cov nroj tsuag thaiv. Ntawm lub tshuab raug, hloov pwm yuav siv li 20 mus rau 30 feeb, uas txo cov zis los ntawm 150 mus rau 200 blocks ib qho kev hloov. QGM Block Making Machine nta hydraulic ceev-clamp system uas tso cai rau ib tus neeg teb xov tooj hloov pwm hauv qab 5 feeb. Rau lub Hoobkas uas hloov pwm ob zaug ib hnub twg (piv txwv li, ua hollow blocks thaum sawv ntxov thiab pavers thaum tav su), peb lub tshuab txuag 40 feeb ntawm downtime txhua hnub, ntxiv roughly 500 ntxiv blocks ib hnub twg. Kev hloov pauv ceev kuj tseem tshem tawm qhov xav tau ntawm cov cuab yeej nqa hnyav, raws li cov pwm qhia kev tsheb nqaj hlau thiab clamping wedges pub phau ntawv zawv zawg pwm hnyav txog 500 kg.

Nqe Lus Nug 5: Kev txhawb nqa dab tsi Quangong Machinery Co., Ltd. muab los pab peb ua kom muaj txiaj ntsig txhua hnub los ntawm QGM Block Making Machine?

Teb: Peb pob nyiaj pab txhawb nqa yog dav. Peb muab kev saib xyuas kev teeb tsa ntawm qhov chaw thiab 5-hnub kev cob qhia tus neeg teb xov tooj ntawm peb lub Hoobkas lossis ntawm koj qhov chaw. Peb kuj muab cov ncauj lus kom ntxaws ntau lawm phau ntawv nrog optimized cycle parameters rau hom block hom. Tom qab ua haujlwm, peb pab pawg kuaj mob tej thaj chaw deb saib xyuas koj lub tshuab los ntawm kev sib txuas ntawm huab (yeem) thiab ceeb toom koj txog tej yam teeb meem ua ntej lawv cuam tshuam rau kev tsim khoom. Peb tuav cov khoom seem thoob ntiaj teb nrog 95 feem pua ​​​​ntawm cov khoom muaj nyob rau tib hnub xa. Tsis tas li ntawd, peb lub Hoobkas muab kev lees paub txog kev tsim khoom: yog tias koj lub QGM Block Making Machine tsis ua tiav cov txiaj ntsig txhua hnub tau teev tseg hauv koj daim ntawv cog lus hauv thawj lub hlis, peb yuav muab kev pabcuam pub dawb kom txog thaum nws ua. Qhov kev cog lus rau cov neeg siv khoom zoo no yog vim li cas Quangong Machinery Co., Ltd. tau ntseeg los ntawm cov chaw tsim khoom hauv ntau tshaj 80 lub teb chaws.

Xaus: Ua tiav Kev Tsim Kho Tshiab Tshiab nrog QGM Thaiv Ua Tshuab

Kev tsim tawm txhua hnub nyob rau hauv cov pob zeb ua vaj tse tsis yog hais txog cov tshuab nrawm dua - nws yuav tsum muaj kev sib koom ua ke uas suav nrog kev vibration efficiency, hydraulic kev ua haujlwm, automation, thiab txo qis qis. QGM Block Ua Tshuab xa tag nrho plaub los ntawm nws cov kev co siab zaus, servo-tsav hydraulics, hloov pwm tsim sai, thiab kev tswj software ntse. Peb lub Hoobkas ntawm Quangong Machinery Co., Ltd. tau tsim txhua yam khoom siv los ua haujlwm sib haum xeeb, txo lub sijhawm voj voog mus txog 50 feem pua ​​​​thiab nce cov sij hawm ntau lawm los ntawm 20 feem pua. Qhov tshwm sim yog lub tshuab ua kom muaj txiaj ntsig txhua hnub los ntawm 40 mus rau 60 feem pua, tso cai rau cov tuam txhab thaiv kom tau raws li qhov xav tau loj hlob, txo tus nqi ib ntus, thiab txhim kho cov txiaj ntsig.

Npaj txhij los hloov koj cov block ntau lawm? Hu rau Quangong Machinery Co., Ltd. hnub norau kev ntsuam xyuas cov zis. Muab koj cov kev qhia tshwj xeeb ntawm lub tshuab tam sim no, thaiv qhov loj me, thiab lub sijhawm ua haujlwm, thiab peb pab neeg ua haujlwm engineering yuav npaj cov lus pom zoo uas qhia meej npaum li cas ntxiv cov zis koj tuaj yeem ua tiav nrog QGM Block Making Machine. Peb muab kev xaiv nyiaj txiag yooj yim, kuaj dawb ntawm peb lub Hoobkas, thiab 2-xyoo lav rau tag nrho cov khoom loj.Thov koj qhov kev sab laj pub dawb tam sim no thiab pib tsim ntau cov blocks-thiab tau nyiaj ntau dua-nrog QGM Block Making Machine. Hloov kho kom zoo rau Quangong Machinery Co., Ltd.
